This product Low cost mini concrete batching plant for sale is equipped with the storage, batching, conveying, stirring, control and other devices of various raw materials required for precast concrete, and various aggregates, powders, admixtures, water, etc.A complete set of equipment for supplying concrete in a concentrated manner than by a mixer.
The 90m ³ no foundation concrete mixing plant has a simple structure, easy installation and disassembly, convenient construction, and is suitable for various complex environments. Widely used in various large and medium-sized industrial and civil buildings such as bridges, highways, water conservancy projects, docks, etc. The HZS90 cement mixing plant can effectively mix dry and hard concrete, lightweight aggregate concrete, and various mortars, making it an ideal equipment for producing commercial concrete.
The production capacity of HZS90 concrete mixing plant is 90m3/h, which is flexibly composed of JS1500 double axis concrete mixer, PLD2400 batching machine, cement silo, control system and related equipment. On the other hand, the 0.75m3 dual axis concrete mixer is highly efficient and can work independently.
| Theoretical productivity of foundation-free HZS90 concrete mixing station | 90m3/h |
| concrete mixer model | JS1500 |
| Stirring motor power | 2×30kW |
| cycle period | 60s |
| Mixer nominal capacity | 1500L |
| The largest particle size of aggregate | Φ80mm |
| Powder bin capacity | 3×100t |
| Batching station batching capacity | 2400L |
| Aggregate bin capacity | 3×20m3 |
| Aggregate type | 3 |
| Aggregate Belt Conveyor Productivity | 600t/h |
| screw conveyor maximum productivity | 80t/h |
| Discharging height | 4.2m |
| Installed capacity | 164kW |
| Aggregate weighing range and accuracy | (0~5000)±2%kg |
| Cement weighing range and accuracy | (0~900)±1%kg |
| Fly ash weighing range and accuracy | (0~500)±1%kg |
| Water weighing range and accuracy | (0~400)±1%kg |
| Admixture weighing range and accuracy | (0~50)±1%kg |
| Standard reference total | 97×103kg |
Our company firmly promises to tailor-make products for each customer, strictly inspect, deliver on time, assist in formulating construction plans, and provide guidance on installation, debugging, and technical training and maintenance free of charge. We will conduct regular inspections in the future and provide improvement plans.
Please fill in the following form and leave your requirements, contact number, equipment usage location and other information, and describe the product requirements as detailed as possible. We will quickly process the information you submit and ensure that your purchase inquiry receives a timely and accurate response.
