The JS1500 forced mixer can produce 1.5 cubic meters per time and has a theoretical productivity of 75m3/h. It is a high-efficiency model and is mostly used as the host of HZS75 or HZS90 concrete mixing stations.
The JS1500 double horizontal shaft forced mixer has a reasonable structure design and adopts a dual motor and dual planetary motor statistical box design. High-quality statistical machines have long service life, wide statistical range, high accuracy, and large output reports. Savings while ensuring efficiency. Consumes electricity and reduces concrete production costs。
The JS1500 forced mixer has expanded the cylinder volume ratio, optimized the design data of the mixing device, reduced the mixing resistance, and reduced the shaft-holding bolts of the mixing device.
| Item/Parameter/Model | JS1500 | |
| Discharge capacity | 1500L | |
| Feed capacity | 2400L | |
| productivity | ≥75m³/h | |
| Maximum particle size of aggregate (pebbles, gravel)mm | 80/60 | |
| Mixing blade | Speed | 25.5r/min |
| quantity | 2×10 | |
| Stirring motor | model | Y225M-4 |
| power | 45kw | |
| Hoist motor | model | YEZ180L-4 |
| power | 18.5KW | |
| water pump motor | model | KQW65-100I |
| power | 3KW | |
| Hopper lifting speed | 23m/min | |
| Overall dimensions | Shipping status | 5068× 2250× 2440mm |
| (length×width×height) | working status | 9645× 3436× 9700mm |
| Overall machine quality | 11130kg | |
| Discharging height | 3800mm | |
The JS1500 double horizontal shaft forced mixer has uniform mixing, high mixing efficiency, reasonable structural design, environmental protection, low energy consumption, and easy use and maintenance.
