Jinhuiyuan Machinery is committed to the production and sales of high-quality PLD1600 batching machines for mixing stations. We can customize PLD1600 batching machines suitable for their own working environment according to different customer needs. The PLD1600 batching machine for mixing stations has a high concrete mix ratio and can mix more than three types of materials. It can be used with various types of concrete mixers and other metering devices, and can be combined into fully automatic and semi-automatic mixing stations.
| project | PLD1600 concrete batching machine |
| Storage hopper capacity | 6/12 m³ |
| Types of ingredients | 2/3/4 types |
| Measuring bucket capacity | 1.6m³ |
| Batching accuracy | ±2% |
| Measurement method | electronic metering |
| Machine power | 3×3kw 4×3kw 4×3kw 5.5kw |
| Overall machine quality | 4500Kg 5100Kg 8000Kg |
The PLD1600 sand and gravel batching machine can effectively ensure the accuracy of the mix ratio of cement, sand, gravel, etc., and the use of an electronic weighing system further improves the accuracy of weighing. The weighing hopper capacity of the PLD1600 batching machine is 1600L, each storage hopper has a capacity of 5 cubic meters, and the batching accuracy is ±2%; the maximum weighing value is 3000Kg; the batching types are 2-5. The equipment can weigh 4 kinds of aggregates at the same time, with short metering time and high efficiency; the head of the belt conveyor is equipped with a material blocking cover to effectively prevent spilling; the tail is equipped with a screw tensioning device, which can adjust the tension of the belt at any time, which is convenient and fast; vibrators are installed on the side walls of the sand bin and the sand weighing hopper, which is conducive to rapid weighing and rapid unloading of rough and fine weighing, with high weighing accuracy; the overall structure is reasonable, strong rigidity and beautiful; the conveying is stable to ensure normal feeding.
